ECS 1997-2004 Corvette Legend Series 2200 Supercharger System With Direct Drive

1997-2004 Corvette Legend Series 2200 Supercharger System With Direct Drive

The Legend Series 2200 is ECS's race version of its C5 Corvette supercharger system, here with Direct Drive, for 1997-2004 cars. It is built around 2200-series Paxton head units. ECS quotes a 250-400+ HP gain depending on options, for C5 owners targeting high power.

What's included

• Belt-driven Paxton centrifugal supercharger (head unit per the options you select)
• Billet aluminum mounting bracket assembly with idler, drive belt and hardware
• Heavy-duty belt tensioners and fixed idlers on double-walled ball bearings
• Intercooler and 6061 aluminum ducting with MAF locations
• Blow-off valve
• Fuel injectors
• Crank pin kit and a new GM crank bolt
• PCV oil separator and ECS valve cover breather
• Reusable high-flow air filter and air inlet restrictor plate
• Heat-resistant silicone sleeves with stainless T-bolt clamps
• New 160 degree thermostat

Key specifications

• Added power: approximately 250-400hp on an otherwise stock car (250-400+ HP depending on options)
• 2200 CFM Paxton head units support 1000+HP
• Intercooler core: 17 x 3.5 x 8 in with a 3 inch inlet and 4 inch outlet, proven past 1000 hp
• Brackets machined from 3/4 in billet aluminum
• Fits under the stock hood and works with factory OBD II engine management
• Finish: black or polished

Before you order

The power gain depends on the head unit, drive and fuel options you pick, so tell us the configuration you want. Send us your year, model and current setup and we will confirm fitment before you order.
