ECS 2006-2013 Corvette Z06 Legend Series 2200 Supercharger System With Direct Drive

2006-2013 Corvette Z06 Legend Series 2200 Supercharger System With Direct Drive

This is the ECS Legend Series 2200 system with Direct Drive for the 2006-2013 C6 Z06. It is the race version of the company's long-running supercharger kit and uses 2200-series Paxton head units. ECS quotes 250-400+ HP added depending on options, for Z06 owners targeting high power.

What's included

• Belt-driven Paxton centrifugal supercharger (head unit per the options you select)
• Billet aluminum mounting bracket assembly with idler, drive belt and hardware
• Heavy-duty belt tensioners and fixed idlers on double-walled ball bearings
• Intercooler and 6061 aluminum ducting with MAF locations
• Blow-off valve
• Fuel injectors
• Crank pin kit and a new GM crank bolt
• PCV oil separator and ECS valve cover breather
• Reusable high-flow air filter and air inlet restrictor plate
• Heat-resistant silicone sleeves with stainless T-bolt clamps
• New 160 degree thermostat
• New NGK spark plugs: TR-6 for LS2/LS3 cars, TR-7IX for LS7 cars

Key specifications

• Platform: 2006-2013 C6 Z06
• Added power: approximately 250-400hp on an otherwise stock car (250-400+ HP depending on options)
• 2200 CFM Paxton head units support 1000+HP
• Intercooler core: 17 x 3.5 x 8 in with a 3 inch inlet and 4 inch outlet, proven past 1200 hp
• Brackets machined in-house by ECS from 3/4 in billet aluminum, with steel idlers and a slide idler for belt wrap
• Fits under the stock hood and works with factory OBD II engine management
• Finish: black or polished

Before you order

The supplier's text lists fuel injectors among the contents but also says tuner versions come without fuel system parts, so the fuel parts for your configuration must be confirmed. Send us your year, model and current setup and we will confirm fitment before you order.

See also: Paxton Novi 1200 vs 1500 vs 2200 · supercharger kit prices · how long a supercharger lasts · is a supercharger worth it? · supercharger maintenance · LS7 supercharger kits · Corvette parts by generation · c6 corvette supercharger kits · all ECS supercharger kits and parts by platform.

Shipping and returns

Shipping is a flat $80.00 per order to US addresses, and returns are free within 15 days of delivery. Questions before you order? Ask a parts specialist.
